Building a Live Chat Support System with Supabase Realtime and Next.js 15

Customer support is the backbone of any successful SaaS business. While tools like Intercom and Zendesk are excellent, they can be expensive for early-stage startups. What if you could build your own live chat support system that's just as powerful, but integrated directly into your application stack?

In this post, I'll walk you through building a production-ready live chat support system using Supabase Realtime, Next.js 15, and React - complete with anonymous user support, real-time messaging, and a comprehensive admin dashboard.

Why Build Your Own Chat System?

Before diving into the implementation, let's understand why building your own chat system makes sense:

Cost Control: Third-party chat solutions can cost $50-200+ per agent per month
Data Ownership: All conversations and customer data stays in your database
Custom Integration: Deep integration with your existing user system and workflows
No Vendor Lock-in: Full control over features, scaling, and future development
Brand Consistency: Matches your app's design and user experience perfectly

Architecture Overview

Our chat system consists of several key components:

┌─────────────────┐    ┌─────────────────┐    ┌─────────────────┐
│   Customer UI   │    │   Agent Admin   │    │   Database      │
│                 │    │                 │    │                 │
│ • ChatBubble    │    │ • Dashboard     │    │ • chat_sessions │
│ • ChatWindow    │    │ • AgentView     │    │ • chat_messages │
│ • ChatProvider  │    │ • Session Mgmt  │    │ • user_profiles │
└─────────────────┘    └─────────────────┘    └─────────────────┘
         │                       │                       │
         └───────────────────────┼───────────────────────┘
                                 │
                    ┌─────────────────┐
                    │ Supabase        │
                    │ Realtime        │
                    │ WebSockets      │
                    └─────────────────┘

Database Schema

The foundation of our chat system is built on two main tables:

-- Chat sessions table
CREATE TABLE chat_sessions (
  id UUID PRIMARY KEY DEFAULT gen_random_uuid(),
  user_id UUID REFERENCES user_profiles(id),
  anonymous_id TEXT,
  agent_id UUID REFERENCES user_profiles(id),
  status TEXT NOT NULL DEFAULT 'open',
  created_at TIMESTAMPTZ DEFAULT NOW(),
  updated_at TIMESTAMPTZ DEFAULT NOW(),
  closed_at TIMESTAMPTZ
);

-- Chat messages table
CREATE TABLE chat_messages (
  id UUID PRIMARY KEY DEFAULT gen_random_uuid(),
  session_id UUID NOT NULL REFERENCES chat_sessions(id) ON DELETE CASCADE,
  sender_id UUID REFERENCES user_profiles(id),
  sender_type TEXT NOT NULL CHECK (sender_type IN ('customer', 'agent')),
  content TEXT NOT NULL,
  created_at TIMESTAMPTZ DEFAULT NOW()
);

Key design decisions:

Anonymous Support: The anonymous_id field allows support for non-authenticated users
Session Management: Status tracking (open/assigned/closed) enables proper workflow management
Flexible Sender Types: Clear distinction between customer and agent messages
Cascading Deletes: When a session is deleted, all related messages are automatically removed

Building the Monorepo Package

Following modern development practices, we built this as a standalone package (@elite-saas/support-chat) that can be easily extracted and reused across projects.

Package Structure

packages/support-chat/
├── src/
│   ├── components/          # Customer-facing UI
│   │   ├── ChatBubble.tsx   # Floating chat button
│   │   ├── ChatWindow.tsx   # Chat interface
│   │   ├── ChatProvider.tsx # Context provider
│   │   └── SupportChat.tsx  # Main component
│   ├── admin/               # Agent dashboard
│   │   ├── SupportDashboard.tsx
│   │   └── ChatAgentView.tsx
│   ├── hooks/               # React hooks
│   │   ├── useChatRealtime.ts
│   │   └── useChatSession.ts
│   ├── services/            # Business logic
│   │   └── chat-service.ts
│   └── types/               # Local types
│       └── chat.ts
├── package.json
└── tsconfig.json

This modular approach ensures:

Clean separation between customer and admin interfaces
Reusable hooks for different use cases
Service layer abstraction for database operations
Type safety throughout the application

Real-time Implementation with Supabase

The heart of our chat system is Supabase's real-time functionality. Here's how we implemented it:

Custom Realtime Hook

export function useChatRealtime({
  sessionId,
  onNewMessage,
  onSessionUpdate,
}: UseChatRealtimeOptions) {
  const [isConnected, setIsConnected] = useState(false);
  const [error, setError] = useState<string | null>(null);
  const channelRef = useRef<RealtimeChannel | null>(null);

  useEffect(() => {
    if (!sessionId || !supabase) return;

    const channel = supabase
      .channel(`chat_session_${sessionId}`)
      .on(
        "postgres_changes",
        {
          event: "INSERT",
          schema: "public",
          table: "chat_messages",
          filter: `session_id=eq.${sessionId}`,
        },
        (payload) => {
          const newMessage = payload.new as SupportChatMessage;
          onNewMessage?.(newMessage);
        },
      )
      .on(
        "postgres_changes",
        {
          event: "UPDATE",
          schema: "public",
          table: "chat_sessions",
          filter: `id=eq.${sessionId}`,
        },
        (payload) => {
          const updatedSession = payload.new as ChatSession;
          onSessionUpdate?.(updatedSession);
        },
      )
      .subscribe((status) => {
        setIsConnected(status === "SUBSCRIBED");
        if (status === "CHANNEL_ERROR") {
          setError("Failed to connect to chat");
        }
      });

    channelRef.current = channel;

    return () => {
      channel.unsubscribe();
    };
  }, [sessionId, supabase, onNewMessage, onSessionUpdate]);

  return { isConnected, error };
}

This hook handles:

Connection management with automatic reconnection
Message subscriptions for real-time updates
Session updates for status changes
Error handling with user feedback

Anonymous User Support

One of the key features is supporting anonymous users who haven't signed up yet:

// Generate anonymous ID for non-authenticated users
useEffect(() => {
  if (!userId) {
    const stored = localStorage.getItem(CHAT_CONFIG.ANONYMOUS_ID_STORAGE_KEY);
    if (stored) {
      setAnonymousId(stored);
    } else {
      const newId = `anon_${Date.now()}_${Math.random()
        .toString(36)
        .substr(2, 9)}`;
      localStorage.setItem(CHAT_CONFIG.ANONYMOUS_ID_STORAGE_KEY, newId);
      setAnonymousId(newId);
    }
  }
}, [userId]);

This approach:

Persists across browser sessions using localStorage
Generates unique identifiers to track conversations
Seamlessly transitions when users sign up later
Maintains conversation history even for anonymous users

Service Layer Architecture

Following clean architecture principles, all database operations are abstracted into a service layer:

export class ChatService {
  constructor(private supabase: SupabaseClient) {}

  async createSession(params: CreateSessionParams): Promise<ChatSession> {
    const sessionData: any = {
      status: "open",
    };

    if (params.userId) {
      sessionData.user_id = params.userId;
    } else if (params.anonymousId) {
      sessionData.anonymous_id = params.anonymousId;
    } else {
      throw new ChatError("Either userId or anonymousId must be provided");
    }

    const { data, error } = await this.supabase
      .from("chat_sessions")
      .insert(sessionData)
      .select()
      .single();

    if (error) throw new ChatError("Failed to create session", error);
    return data;
  }

  async sendMessage(params: SendMessageParams): Promise<SupportChatMessage> {
    const { data, error } = await this.supabase
      .from("chat_messages")
      .insert({
        session_id: params.sessionId,
        sender_id: params.senderId,
        sender_type: params.senderType,
        content: params.content.trim(),
      })
      .select()
      .single();

    if (error) throw new ChatError("Failed to send message", error);
    return data;
  }
}

Benefits of this approach:

Centralized business logic for easy testing and maintenance
Consistent error handling across the application
Type-safe operations with full TypeScript support
Easy mocking for unit tests

Row Level Security (RLS) Implementation

Security is critical for a chat system. We implemented comprehensive RLS policies:

-- Messages: Users can only see messages from their own sessions
CREATE POLICY "Users can view their own session messages" ON chat_messages
FOR SELECT USING (
  session_id IN (
    SELECT id FROM chat_sessions
    WHERE user_id = auth.uid()
    OR anonymous_id = current_setting('app.anonymous_id', true)
  )
);

-- Agents can see all messages
CREATE POLICY "Support agents can view all messages" ON chat_messages
FOR SELECT USING (
  EXISTS (
    SELECT 1 FROM user_profiles
    WHERE id = auth.uid() AND is_support_agent = true
  )
);

This ensures:

Data isolation between different customer sessions
Agent access to all conversations for support purposes
Anonymous user protection using session settings
Automatic enforcement at the database level

Admin Dashboard Features

The admin dashboard provides agents with everything they need:

Session Management

Real-time session list with status indicators
Unread message counts for prioritization
One-click assignment to take ownership of conversations
Session status updates (open/assigned/closed)

Agent Interface

export function ChatAgentView({ sessionId, onBack }: ChatAgentViewProps) {
  const [session, setSession] = useState<ChatSession | null>(null);
  const [messages, setMessages] = useState<SupportChatMessage[]>([]);

  // Real-time message updates
  useChatRealtime({
    sessionId,
    onNewMessage: (message) => {
      setMessages((prev) => [...prev, message]);
    },
    onSessionUpdate: (updatedSession) => {
      setSession(updatedSession);
    },
  });

  const handleSendMessage = async (content: string) => {
    await chatService.sendMessage({
      sessionId,
      senderId: currentUser.id,
      senderType: "agent",
      content,
    });
  };
}

Key features:

Real-time message delivery with instant updates
Message history with sender identification
Session controls for assignment and closure
Responsive design for mobile and desktop use

Performance Optimizations

Several optimizations ensure smooth operation at scale:

Message Pagination

const { data: messages } = await supabase
  .from("chat_messages")
  .select("*")
  .eq("session_id", sessionId)
  .order("created_at", { ascending: true })
  .range(offset, offset + MESSAGES_PER_PAGE - 1);

Connection Pooling

Shared Supabase client instances across components
Connection reuse for multiple subscriptions
Automatic cleanup when components unmount

Optimistic Updates

const sendMessage = useCallback(async (content: string) => {
  // Optimistic update for immediate UI feedback
  const optimisticMessage = {
    id: `temp-${Date.now()}`,
    content,
    sender_type: senderType,
    created_at: new Date().toISOString(),
  };

  setMessages(prev => [...prev, optimisticMessage]);

  try {
    await chatService.sendMessage({...});
  } catch (error) {
    // Revert on error
    setMessages(prev => prev.filter(m => m.id !== optimisticMessage.id));
    throw error;
  }
}, []);

Integration and Usage

Integrating the chat system into your app is straightforward:

1. Provider Setup

// app/layout.tsx
import { ChatProvider } from "@elite-saas/support-chat";

export default function RootLayout({ children }) {
  return (
    <html>
      <body>
        <ChatProvider supabase={supabase} userId={user?.id}>
          {children}
        </ChatProvider>
      </body>
    </html>
  );
}

2. Add Chat to Pages

// Any page component
import { SupportChat } from "@elite-saas/support-chat";

export default function HomePage() {
  return (
    <div>
      <h1>Welcome to our app</h1>
      <SupportChat />
    </div>
  );
}

3. Admin Dashboard

// admin/support/page.tsx
import { SupportDashboard } from "@elite-saas/support-chat";

export default function SupportPage() {
  return <SupportDashboard />;
}

Next Steps and Enhancements

This implementation provides a solid foundation that can be extended with:

File attachments for screenshots and documents
Canned responses for common support queries
Chat routing based on user tier or issue type
Analytics dashboard for support metrics
Mobile push notifications for agents
Multilingual support for international customers
AI-powered chatbots for initial triage

Conclusion

Building your own live chat support system gives you complete control over the customer experience while keeping costs manageable. With Supabase's real-time capabilities and Next.js 15's performance optimizations, you can create a system that rivals expensive third-party solutions.

The modular architecture ensures you can start simple and add features as your business grows. Most importantly, you own the entire customer interaction history, giving you valuable insights for improving your product and support processes.
